Eclipse

Line Center

Linear sound source module

Precision Sound: Claim Your Front-Row Experience

The Line Center is specifically designed for the center channel in home theaters, featuring a precise array system composed of 4 CarbonEcho x 6.5 mid-bass units and 6 AMT Array air motion tweeters.
With an acoustically symmetrical layout and a fully sealed aircraft-grade aluminum cabinet, it maintains a THD of less than 0.8% even at a peak sound pressure level of 121dB.
Additionally, it locks the horizontal dispersion at ±30° and compresses the vertical dispersion to ±5°, achieving a positioning error of less than 0.5° even when deviated 45° from the sweet spot.
— Whether it's the lip-sync details of the atomic bomb hearing in "Oppenheimer" or the epic battles in "Dune", the Line Center ensures that every line of dialogue hits the ear with emotion.

Fully-Sealed Aerospace Aluminum Chassis

A Masterpiece of Acoustic Engineering

The Line Center features a fully sealed 6021 military-grade aviation aluminum enclosure, a super-rigid structure composed of an axially symmetrical dual-resonance chamber and an aviation aluminum support truss, which minimizes resonant interference and reduces distortion transmission to the limit, achieving "mechanical-level precision" in sound. Meanwhile, it is equipped with a modular acoustic array system inside: 4x CarbonEcho X6.5 mid-bass units and 6x AMT miniature pneumatic tweeter arrays, with a maximum output sound pressure of over 115dB, covering a free-field frequency response range from 45Hz to 25kHz. Whether it's the demanding monitoring in a recording studio or the explosive sound pressure in a cinema, it can conquer any acoustic scenario with ultimate precision and energy.

Modular Design

Reproduce Soulful Sound Quality

We consider the Line Center as a complete music system rather than just a mid-high frequency sound module. The AMT pneumatic tweeter array ensures ultra-high frequency extension and detail density; the CarbonEcho X6.5 mid-bass unit perfectly covers the full frequency range from 40Hz to 25kHz.

At the same time, through modular design, you can gradually increase the number of pairs according to the actual space size, to achieve a listening effect with less than 110db full-frequency ultra-low distortion in the listening area, ranging from 20 square meters to 100 square meters. If you want to experience the soulful sound quality that is the hallmark of Cosvox, just one pair of "Line Center" is enough.
